成立于1969年,理波光电集团是激光与光电子器件供应商,具备全球公认的先进技术,产品和解决方案,其产品针对于生命健康科学,微电子技术,航天国防及国家安全,工业制造等市场领域。


产品列表

A1: UV / Vis Gratings

Catalog
  Number

Grooves
  per mm

Nominal Blaze
  Wavelength (1st Order
  Littrow)

Nominal Blaze
  Angle or
  Modulation

Maximum Ruled Area
  (Groove Length x
  Ruled Width, mm)



53-*-058H†

4320

350 nm

high

102 x 128

53-*-551H

4320

275 nm

high

84 x 84

53-*-510H

3600

200 nm

low

102 x 128

53-*-520H†

3600

250 nm

medium

102 x 128

53-*-530H†

3600

300 nm

high

84 x 84

53-*-021R

2700

259 nm

20°

102 x 102

53-*-150R†

2400

240 nm

16.8°

102 x 102

53-*-240R†

2400

300 nm

21°

102 x 102

53-*-400H†

2400

250 nm

blazed

102 x 102

53-*-410H

2400

200 nm

low

102 x 102

53-*-420H†

2400

270 nm

medium

102 x 102

53-*-430H†

2400

400 nm

high

102 x 102

53-*-300R†

2160

500 nm

32.7°

128 x 154

53-*-059H†

2000

475 nm

high

102 x 128

53-*-061R†

1800

250 nm

13°

52 x 52

53-*-310H†

1800

300 nm

low

102 x 102

53-*-289R†

1800

400 nm

21.1°

102 x 102

53-*-290R†

1800

500 nm

26.7°

102 x 102

53-*-300H†

1800

250 nm

blazed

102 x 102

53-*-320H†

1800

450 nm

medium

102 x 102

53-*-330H†

1800

500 nm

high

102 x 128

53-*-233H†

1760

550 nm

high

102 x 102

53-*-128R

1714.3

650 nm

34°

102 x 102

53-*-136H†

1714

550 nm

high

102 x 102

53-*-285R†

1700

530 nm

22.49°

102 x 102

53-*-331H

1700

550 nm

high

84 x 84

53-*-070R

1500

250 nm

10.8°

52 x 52

53-*-188R

1201.6

250 nm

8.6º

102 x 102

53-*-200H†

1201.6

250 nm

blazed

102 x 102

53-*-210H

1200

450 nm

low

64 x 64

53-*-060R†

1200

250 nm

8.6°

154 x 206

53-*-047R†

1200

450 nm

15.7°

102 x 102

53-*-340R†

1200

600 nm

21°

204 x 306

53-*-280R†

1200

500 nm

17.5°

154 x 206

53-*-330R†

1200

400 nm

14°

102 x 128

53-*-105R

1000

250 nm

7.2°

102 x 102

53-*-112H†

1000

230 nm

blazed

110 x 110

53-*-462R†

964

520 nm

14.6°

64 x 64

53-*-262H†

950

1 μm

high

102 x 102

53-*-266R†

900

550 nm

14.3°

154 x 206

53-*-455R†

700

530 nm

10.5°

50 x 50

53-*-267R†

600

650 nm

11.3°

154 x 206

53-*-260R†

600

500 nm

8.6°

154 x 206

53-*-010R†

600

300 nm

5.2°

154 x 206

53-*-080R†

600

400 nm

154 x 206

53-*-264R

588

561 nm

9.5°

52 x 52

53-*-246R†

500

560 nm

154 x 206

53-*-230R†

500

330 nm

4.7°

102 x 102

53-*-183R†

400

250 nm

2.9

104 x 102

53-*-581R†

400

550 nm

6.3°

102 x 128

53-*-586R†

400

400 nm

4.5°

154 x 206

53-*-222R

384.6

605 nm

6.7°

102 x 102

53-*-321R†

333

600 nm

5.7°

64 x 64

53-*-225R

316

550 nm

154 x 206

53-*-204R

300

550 nm

4.7°

102 x 102

53-*-090R†

300

300 nm

2.5°

154 x 206

53-*-091R†

300

422 nm

3.6°

154 x 206

53-*-172R†

300

280 nm

2.4

104 x 102

53-*-327R

300

325 nm

2.8°

102 x 102

53-*-270R†

300

500 nm

4.3°

154 x 206

53-*-126R†

258

315 nm

2.4°

64 x 76

53-*-346R†

200

730 nm

4.2°

102 x 102

53-*-201R†

150

500 nm

2.2°

128 x 154

53-*-202R†

150

300 nm

1.2°

102 x 102

53-*-616R

121.6

410 nm

1.44°

52 x 52

53-*-065R

120

330 nm

1.1°

102 x 102

53-*-666R

110

253.8 nm

0.8°

102 x 102

53-*-310R†

50

600 nm

0.8°

128 x 206



A2: Fiber Optic Telecommunication Gratings

Catalog
  Number

Grooves
  per mm

Working
  Diffraction
  Order

Equivalent
  Dispersion
  (grooves/mm)

Telecom
  Band

Characteristics



53-*-230H†

1200

1

1200

S and C

High S-Plane diffraction   efficiencies

53-*-544H†

1100

1

1100

S, C and L

High S-Plane diffraction   efficiencies

53-*-245H†

1050

1

1050

S, C and L

High S-Plane diffraction   efficiencies

53-*-248H

1033

1

1033

1250-1450 nm

High S-Plane diffraction   efficiencies

53-*-253H

1033

1

1033

1250-1450 nm

High diffraction efficiencies for   S&P
  polarizations with low PDL

53-*-148R†

1000

1

1000

S, C and L

High S-Plane diffraction efficiencies

53-*-262H†

950

1

950

S, C and L

High S-Plane diffraction   efficiencies

53-*-269H†

900

1

900

S, C and L

High S-Plane diffraction   efficiencies

53-*-024R

600

2

1200

C

High diffraction efficiencies for   S&P
  polarizations with low PDL

53-*-660R†

600

1

600

C

High diffraction efficiencies for   S&P
  polarizations with low PDL

53-*-013R†

300

3

900

C

High diffraction efficiencies for   S&P
  polarizations with very low PDL

53-*-154R

286.52

3

859.5

L

High diffraction efficiencies for   S&P
  polarizations with low PDL

53-*-415E

52.67

22

1158.7

C

High diffraction efficiencies for   S&P
  polarizations with moderately low PDL



A3: Dye Laser Tuning Gratings

Catalog
  Number

Grooves
  per mm

Maximum
  Ruled Area
  (Groove Length x
  Ruled Width, mm)

Nominal
  Blaze
  Angle



53-*-530H†

3600

84 x 84

holographic

53-*-430H†

2400

102 x 102

holographic

53-*-059H†

2000

102 x 102

holographic

53-*-290R†

1800

102 x 102

26.7°

53-*-330H†

1800

102 x 102

holographic

53-*-466R†

600

102 x 102

54.1°

A4: Molecular Laser Tuning Gratings

Type

Wavelength
  Range

Catalog
  Number

Grooves
  per mm

Nominal
  Blaze
  Angle

Diffraction
  Angle

Maximum
  Ruled Area
  (Groove Length x
  Ruled Width, mm)



F2

157.1 nm

53-*-141E

154.51

76

76.1

128 x 260

ArF

193.3 nm

53-*-071E

112.96

79

79

128 x 258

53-*-406E

85.837

76

76.1

128 x 254

53-*-141E

154.51

76

76.1

128 x 260

53-*-084E

117.94

79

79

128 x 258

KrF

248.3 nm

53-*-402E

79.01

74

74

128 x 254

53-*-071E

112.96

79

79

128 x 258

Parametric

1.4-2.1 μm

53-*-525R†

830.8

30

39

154 x 206

53-*-550R†

600

28.7

29

154 x 206

HF

2.8-3 μm

53-*-676R

420

26.7

37.5

52 x 52

53-*-736R†

300

22

26

102 x 102

DF

3.5-4.1 μm

53-*-440R†

300

36.8

31.7

154 x 206

53-*-820R†

240

26.7

24.8

90 x 102

53-*-676R

420

26.7

47

52 x 52

HBr

4.1-4.8 μm

53-*-820R†

240

28.7

32.3

90 x 102

53-*-440R†

300

36.8

41.9

154 x 206

CO, NO

4.8-6.2 μm

53-*-440R†

300

36.8

51.1

154 x 206

53-*-820R†

240

26.7

42.2

90 x 102

53-*-880R†

150

26.7

24.8

154 x 206

CO2, N2O

9.6-11.3 μm

53-*-005R†

79.35

35

24.8

64 x 58

53-*-885R†

135

30

45.7

64 x 64

53-*-960R

75

26.7

23.4

154 x 206

53-*-036R

90

26.7

28.5

102 x 102

53-*-831R

120

26.7

39.5

65 x 76

53-*-830R

100

22

32

102 x 128

53-*-880R†

150

26.7

52.6

154 x 206

CO2 Isotope

16 nm

53-*-005R†

79.35

35

39.4

64 x 58

53-*-910R

50

26.7

23.5

154 x 206

53-*-920R

60

28.7

28.7

154 x 206



A5: Large Astronomical Gratings

Catalog
  Number

Grooves
  per mm

Nominal Blaze
  Wavelength (1st Order
  Littrow)

Nominal Blaze
  Angle

Maximum Ruled Area
  (Groove Length x
  Ruled Width, mm)



53-*-109R

1000

460 nm

13.5°

230 x 260

53-*-147R

1000

330 nm

10.3°

230 x 260

53-*-461R

632

800 nm

14.7°

306 x 408

53-*-561R

632

1.2 μm

22.3°

306 x 408

53-*-571R

632

2.65 μm

57°

306 x 408

53-*-068R

600

620 nm

10.7°

308 x 408

53-*-083R

600

510 nm

9.5°

230 x 210

53-*-601R

452

1.14 μm

15°

209 x 310

53-*-584R

400

415 nm

4.76°

306 x 408

53-*-505R

316

1.2 μm

11°

300 x 370

53-*-137R

316

870 nm

7.6°

308 x 414

53-*-181R

316

750 nm

6.8°

160 x 218

53-*-273R

270

533 nm

4.13°

306 x 408

53-*-271R

250

600 nm

4.5°

306 x 408

53-*-179R

245

4.85 μm

36.5°

158 x 208

53-*-187E

124.93

770 nm

66°

154 x 206

53-*-232R†

115

10.4 μm

36.8°

154 x 206

53-*-291E

91.7

All

58.9°

154 x 208

53-*-215R†

80

4.25 μm

9.8°

204 x 408

53-*-856R

75

4.6 μm

10°

210 x 260

53-*-275E

50.7

All

64.2°

154 x 306



 A6: Pulse Compression Gratings


Catalog
  Number

Grooves
  per mm

Nominal
  Blaze
  Wavelength
  (1st Order
  Littrow)

Nominal Blaze Angle (R)
  or
  Modulation Depth (H)

Maximum
  Ruled Area
  (Groove Length x
  Ruled Width, mm)



53-*-430H†

2400

300 nm

high

102 x 102

53-*-059H†

2000

750 nm

high

102 x 128

53-*-330H†

1800

500 nm

high

102 x 128

53-*-233H†

1760

550 nm

high

102 x 102

53-*-239H†

1500

750 nm

high

102 x 102

53-*-230H†

1200

800 nm

high

110 x 110

53-*-340R†

1200

600 nm

21.1°

204 x 306

53-*-360R†

1200

750 nm

26.7°

156 x 206

53-*-727R†

672

832 nm

16.4°

64 x 64

53-*-351R†

600

800 nm

13.9°
