公司简介
美国laser lab Components公司成立于2004年，在2007年转向生产二极管抽运固体(离散长)连续波(CW)、单纵模(SLM),紧凑型Q开关激光器，波长覆盖紫外,蓝色,绿色,黄色,红色,IR。目前专门从事设计,开发和生产面向科研和工业的先进的超快Yb-Doped皮秒和飞秒Mode-Lock光纤振荡器和Yb-Doped直接二极管泵浦晶体基质固体放大器。
产品列表
Mode-Locked Fiber Lasers
| Yb-Doped Mode-Locked Picosecond Fiber Oscillators | |
| Wavelength: 1064nm; | |
| Pulse Duration: 4~8 ps; | |
| Bandwidth (FWHM): 0.3~0.5 nm; | |
| Repetition Rate: 15~50 MHz; | |
| Output Power: 10~30 mW; | |
| Life Time: > 20K Hrs; | |
| Beam Output: PM Fiber Delivery or Free Space; | |
| Amplitude of Syn. Clock Output: 0.8 ~ 1.0 V; | |
| Mode-Locking Real-time Monitoring / Protection: Yes; | |
| Unit Powered: 9~12 VDC; | |
| Operating Temperature: 15~35 C; | |
| Laser Head Dimensions: 2.0" x 5.0" x 8.0"; | |
| Rugged mechanical design replaceable on field. | |
| Yb-Doped Mode-Locked Femtoecond Fiber Oscillators | |
| Wavelength: 1030nm; | |
| Output Pulse Duration: 4~7 ps (compressible to less than 300 fs); | |
| Bandwidth (FWHM): 8.0~10.0 nm; | |
| Repetition Rate: 15~50 MHz; | |
| Output Power: 10~30 mW; | |
| Life Time: >20K Hrs.; | |
| Beam Output: PM Fiber Delivery or Free Space; | |
| Amplitude of Syn. Clock Output: 0.8 ~ 1.0 V; | |
| Mode-Locking Real-time Monitoring / Protection: Yes; | |
| Unit Powered: 9~12 VDC; | |
| Operating Temperature: 15 ~ 35 C; | |
| Laser Head Dimensions: 2.0" x 5.0" x 8.0"; | |
| Rugged mechanical design replaceable on field. | |
DPSS Ultrafast Amplifiers
| DPSS 1064nm Picosecond Hybrid Amplifiers | |
| Wavelength: 1064nm; | |
| Pulse Duration: 5 ~ 10 ps; | |
| Repetition Rate: 50 KHz ~ 1.0 MHz; | |
| Output Power (1064nm): > 10 W (Optional: >5W at 532nm; >3W at 355nm); | |
| Power Stability (RMS): < 1.0%; | |
| Beam Size: ~2 mm; | |
| Beam Quality: M2<1.2; | |
| Seed Source: Fiber Mode-Lock Laser; | |
| Pump Source: Laser Diodes; | |
| System Configuration: Hybrid (Fiber + Free Space); | |
| Cooling: Water Chiller; | |
| Laser Head Dimensions: 10" x 15" x 4"; | |
| Laser Controller: 3U Chassis; | |
| Rugged mechanical design replaceable on field. | |
| DPSS 1030nm High Power Femtosecond Amplifiers | |
| Wavelength: 1030nm; | |
| Pulse Duration: 400 fs ~ 10 ps (Adjustable); | |
| Bandwidth (FWHM): 8~10 nm; | |
| Repetition Rate: 50 KHz ~ 1.0 MHz; | |
| Output Power (1030nm): > 10 W (Optional: >5W at 515nm; >3W at 343nm); | |
| Power Stability (RMS): < 1.0%; | |
| Beam Size: 2~3 mm; | |
| Beam Quality: M2<1.2; | |
| Seed Source: Fiber Mode-Lock Laser; | |
| Pump Source: Laser Diodes; | |
| System Configuration: Hybrid (Fiber + Free Space); | |
| Cooling: Water Chiller; | |
| Laser Head Dimensions: 12" x 15" x 4"; | |
| Laser Controller: 3U Chassis; | |
| Rugged mechanical design replaceable on field. | |
| DPSS 1030nm High Energy Femtosecond Amplifiers | |
| Wavelength: 1030nm; | |
| Pulse Duration: 300 fs ~ 10ps (Adjustable); | |
| Bandwidth (FWHM): 8~10 nm; | |
| Repetition Rate: Single-Shot ~ 200 KHz; | |
| Pulse Energy: up to 2mJ; | |
| Output Power (1030nm): > 10 W (Optional: >5W at 515nm; >3W at 343nm); | |
| Power Stability (RMS): < 1.0%; | |
| Beam Size: 2~3 mm; | |
| Beam Quality: M2<1.2; | |
| Seed Source: Fiber Mode-Lock Laser; | |
| Pump Source: Laser Diodes; | |
| System Configuration: Hybrid (Fiber + Free Space); | |
| Cooling: Water Chiller; | |
| Laser Head Dimensions: 14" x 20" x 5"; | |
| Laser Controller: 3U Chassis; | |
| Rugged mechanical design replaceable on field. | |
