公司简介
FEMTOCHROME公司位于美国加州伯克利大学附近，为超快激光脉冲应用制造最先进的自/互相关仪。
产品列表
1.FR-103XL RAPID SCANNING AUTOCORRELATOR/CROSSCORRELATOR
 | Resolution ® 1 fs Wavelength Range: 410-1800nm Scan Range: > 60ps Sensitivity: (PavPpk)min= 0.3(10)-7W2 Fiber Coupled/Free Space Interferometric/Background-free Low Rep Rate Option Computer Data Acquisition Option VGA Display option
Click here to download pdf datasheet.
|
2.FR-103MN RAPID SCANNING AUTOCORRELATOR/CROSSCORRELATOR
 | Resolution ® 1 fs Wavelength Range: 410-1800nm Scan Range: > 60ps Sensitivity: (PavPpk)min= 0.3(10)-7W2 Fiber Coupled/Free Space Interferometric/Background-free Low Rep Rate Option Computer Data Acquisition Option VGA Display option
Click here to download pdf datasheet.
|
3.FR-103HS AUTOCORRELATOR/CROSSCORRELATOR
 | Resolution: < 3fs Wavelength Range: 410-1800nm Scan Range: > 150ps Sensitivity: (PavPpk)min = 0.5 x 10-8W2 Fiber Coupled/Free Space Interferometric/Background-free Slow Scan Option (any rep rate > 4Hz) Computer Data Acquisition Option VGA Display Option
Click here to download datasheet. |
4.FR-103HP
Compact, cost-effective Autocorrelator/Crosscorrelator for moderate and high power lasers (>5mW avg. power).
5.FR-103WS AUTOCORRELATOR/CROSSCORRELATOR
 | Resolution: < 3fs Wavelength Range: 410-1800nm Scan Range: > 400ps Sensitivity: (PavPpk)min = (10)-6W2 Fiber Coupled/Free Space Interferometric/Background-free Slow Scan Option (any rep rate > 4 Hz) Computer Data Acquisition Option VGA Display Option
Click here to download datasheet.
|
6.FR-103RM RAPID SCANNING CROSSCORRELATOR
1.FR-103PD RAPID SCANNING AUTOCORRELATOR/CROSSCORRELATOR
 | Resolution →1fs Scan Range > 40 ps Wavelength Range: 500 - 3000nm Pulsewidth Range: 5fs - 15 ps Interferometric Polarization insensitive Fiber Coupled/Free space Computer Interface Low rep rate option(> 4Hz) Compact Size: 4.25" x 5" x 5.5"
Click here to download pdf datasheet.
|
2.FR-103MC FEMTOSECOND DETECTOR
 | Wavelength Range: 410 - 3000nm Pulsewidth Range: 5fs - 10ps Fiber Coupled/Free space Compact Size: 4" x 3.25" x 2.5" 'Real-time' for rep rates >10kHz
Click here to download pdf datasheet.
|
3.FR-103TPM AUTOCORRELATOR
 | Pulsewidth Range: 5fs-10ps Wavelength Range: 410-3000nm Fiber Coupled/Free Space Interferometric 'Real-time' for rep rates >10kHz
Click here to download product comparison specs. |
