We have over 40 years of experience in suppling custom optical components and assemblies for OEMs.
Focusing on consistent quality, we deliver value by providing seamless supply from a single source for all production optical requirements.
We promote design for manufacture and work with our customers to take their projects from prototypes through to serial production.
产品列表
Custom lenses
We have extensive experience in supplying custom lenses, including singlets, doublets and aspherics. Below are parameters for typical specifications. Tighter specifications are achievable .
TYPICAL SPECIFICATIONS
Typical specifications
Materials Most crown, flint and UV glass types
Diameter 2-150mm
Diameter tolerance +0/-0.1mm
Radius tolerance +/-1.5mm
Centre-thickness tolerance +0/-0.1mm
Centration 3 arc minutes
Irregularity 1/4 wave
Coating See under custom coatings
Scratch-dig 40/20
Clear aperture 95%
Custom plano-optics
Plano-optics include windows, mirrors and prisms. Parameters listed below are typical specifications. Tighter tolerances are achievable.
TYPICAL SPECIFICATIONS
Materials Most optical glasses
Dimensions 2-250mm
Dimension tolerance +0/-0.1mm
Thickness tolerance +/-0.1mm
Angle tolerance 2 arc minutes
Parallelism 3 arc minutes
Flatness 1/4 wave
Coating See table below
Scratch-dig 40/20
Clear aperture 95%
Custom coatings
We can create almost any custom coating, from basic AR coatings to complex or specialist coatings, such as oleophobic and hydrophobic coatings. The most common coatings are listed below.
| AR COATINGS V-AR coatings are designed for narrow band use. R type. › 0.2%. Broadband AR coatings tend to have higher reflectances the broader the wavelength range. R typ. for visible ‹ 0.4%. | MIRROR COATINGS Metal coatings are versatile and economical. Typical materials include aluminium, gold and silver. Dielectric coatings are normally more costly but offer better performance and durability. |
| BEAMSPLITTER COATINGS Beamsplitter coatings are designed to either be as non-polarising as possible or to distinguish between the two polarisations. | FILTER COATINGSDichroic coatings are all-dielectric and divide a beam spectrally. They are normally designed for 0º or 45º use. For stronger blocking, an interference filter can be used (see custom filters section below). |
Custom filters
Below are typical specifications we work to with optical filters and polarisers. For more demanding specs or complex coatings.
TYPICAL SPECIFICATIONS
Materials Most plastics, filter and optical glasses
Diameter 2-120mm
Diameter tolerance +0/-0.1mm
Thickness tolerance +/-0.1mm
Scratch-dig 60/40
Clear aperture 95%
Coating types Metallic ND, Dichroic, Interference, Dielectric polarising
Custom mechanics
An experimental optical system benefits most from the flexibility and economy of stock mounting systems, such as TubeMount. For serial production, however, an optical system usually needs to be much more compact, more simple to assemble and more economical when produced in volume. This usually requires a custom optomechanical mounting assembly.
Mechanical mounting systems are usually manufactured from aluminium and often black-anodised to reduce stray light reflections. We have extensive experience in creating such custom mechanical parts.
