公司简介
IXYS Colorado is the home of IXYSRF MOSFETs, gate drivers and silicon carbide diodes and DEI Scientific pulse generators and laser diode drivers. We proudly offer customer solutions for laboratory/bench-top, industrial and OEM applications. As a wholly owned subsidiary of IXYS Corporation we have access to expertise and semiconductor processes that allow us to create unique and cost effective solutions for both our standard products as well as for our OEM partners.
产品列表
Handheld Instruments & Signal Generators
 | Whether you're looking for an ultra high speed, high precision signal generator for the bench in your research lab or the portability of a handheld instrument for quick and easy measurements on the go...the Directed Energy line of products delivers! Our instruments feature both 50 Ohm and 1M Ohm termination for a wide variety of load conditions as well as our easy to use touchscreen interface. Ideal for triggering or synchronizing other instruments including our PCX and PVX series of Laser Diode Driver Instruments, Modules and High Voltage Pulse Generator Instruments andModules. |
 | PDG-2500 Handheld Digital Pulse GeneratorThe PDG-2500 is a handheld, battery-operated pulse generator with a frequency range of 5 Hz to 1.000 MHz and a duty cycle range of 0.00 % to 100.00 % |  | SIV-3028 Curve TracerThe SIV-3028 is an industry leading curve tracer that measures the I-V curves of solar cells and solar panels in the lab or field, storing 100 measurements in non volatile memory. |
Laser Diode Driver Instruments
 | Click here for our Laser Diode Driver Instrument Product Selection Guide! DEI Scientific offers a variety of Laser Diode Driver Instruments designed for high power and precision applications for pulsed, QCW and CW operation. High compliance voltages allow for both single diode and diode array use as well as non-laser applications requiring a high current source. These instruments are perfect for research & development, characterization and testing of laser diodes. Our new, easy to use touchscreen interface is featured on our new designs and allow users intuitive control of pulse characteristics. Looking for an OEM laser diode driver module? Visit our Laser Diode Driver Modules Product Catalog here. |
PCX-6425 150A 120V Pulsed Laser Diode DriverThe PCX-6425 is an air-cooled, high-power current source designed to drive laser diodes, bars, and arrays. The output current can be set from 1 A to 150 A. The load voltage can be set from 0 V to 120 V. The pulse width is adjustable from 100 μs to 5,000 μs with a frequency range from single shot to 100 Hz. |
PCX-7401 0.55A CW / 3A Pulsed Laser Diode DriverThe PCX-7401 is an air-cooled, benchtop current source featuring separate 3A pulse and 0.55A bias current adjustment. The system has an internal trigger source offering duty cycle or single shot operation. | |
PCX-7420 5.8A CW / 21.5A Pulsed Laser Diode DriverThe PCX-7420 is an air-cooled, high power CW/QCW bench top current source providing up to 5.8 Amps CW current and 21.5 Amps pulsed current. In pulsed mode, the output may be biased to any CW current from 0.050 Amps to 5.8 Amps and then pulsed up to 21.5 Amps. |
PCX-7500 Series 450A Pulsed Laser Diode DriverThe PCX-7500 is an air-cooled, high power pulsed current source designed to drive laser diodes, bars, and arrays from 10 A to 450 A, compliance voltage from 5V to 110V dependent on the model. Pulse width is adjustable between 4 µs and 5,000 µs. |
Laser Diode Driver Modules
See our Laser Diode Driver Module Product Selection Guide here!
DEI Scientific offers a variety of Laser Diode Driver Modules designed for high power and precision applications for pulsed, QCW and CW operation. High compliance voltages allow for both single diode and diode array use. These Modules are perfect for OEM designs in both permanent or semi-permanent installations.
Looking for a benchtop laser diode driver instrument? Visit our Laser Diode Driver Instruments Product Catalog here.
HPL-2400 Series High Power LoadThe HPL-2400 is a water-cooled, very low inductance high power load, capable of dissipating up to 2400 Watts, available in seven standard load values including .125, .250, .500, 1, 2, 5 and 10 Ohms. |
PCM-7510 250A Laser Diode DriverThe PCM-7510 pulsed laser diode driver delivers current pulses variable from 10 to 250 Amps with up to 1250 Watts of total output power. Pulse widths can vary from 5μS to 5 msec, with rise times and fall times of 2μsec to 8μsec. | |
PCM-7700 200A Laser Diode DriverThe PCM-7700 pulsed laser diode driver delivers current pulses variable from 5 to 200 Amps. Pulse widths can vary from 500μS to 50 msec, with rise times and fall times less than 75μsec. It supports analog and digital control modes. In digital mode, a DC voltage sets the output current and the trigger inputs sets the pulse width. In analog mode, the output current follows an analog signal. |
PCO-6131 125A Laser Diode DriverThe PCO-6131 is a compact, OEM-style high power pulsed current source designed to drive diode lasers, bars and arrays in pulsed, QCW or CW modes. It delivers output current variable from 1A to 125A. | |
PCO-6141 60A Laser Diode DriverThe PCO-6141 is a compact, OEM-style high power pulsed current source designed to drive diode lasers, bars and arrays in pulsed, QCW or CW modes. It delivers output current to 60A. |
PCO-6511 10A CW Laser Diode DriverThe PCO-6511 is a compact, OEM-style current source designed to drive diode lasers, bars and arrays in CW mode from 500mA to 10A. | |
PCO-7110-40-4 40A 4ns Laser Diode DriverThe PCO-7110-40-4 is a compact, economical OEM laser diode driver module designed to provide extremely fast, high current pulses with a 4ns fixed pulse width. |
PCO-7110-50-15 50A 15ns Laser Diode DriverThe PCO-7110-50-15 is a compact, economical OEM laser diode driver module designed to provide extremely fast, high current pulses with a 15ns fixed pulse width. | |
PCO-7120 50A Laser Diode DriverThe PCO-7120 is a compact, economical OEM laser diode driver module designed to provide extremely fast, high current pulses. It offers variable output current from 500mA to 50A, with continuously variable pulse widths from 12ns to >1μs. |
PCO-7810-40-4 40A 4ns Laser Diode DriverThe PCO-7810-40-4 is compact economical OEM laser diode driver module designed to provide 4ns FWHM, high current pulses. It features an internal high voltage DC power supply to support the high current output, and an internal trigger generator. | |
PCO-7810-50-12 50A 12ns Laser Diode DriverThe PCO-7810-50-12 is a compact economical OEM laser diode driver module designed to provide 12ns FWHM, high current pulses at up to 50A. It features an internal high voltage DC power supply to support the high current output, and an internal trigger generator. |
PIM-Mini Series Laser Diode Driver Development KitThe PIM-Mini Development Kit includes everything except the laser to begin laser system development sooner. | |
PIM-Mini Series 5A to 200A Laser Diode DriversThe PIM-Mini Series are a compact and lightweight pulsed current source designed to drive laser diodes, bars, arrays, or any low-impedance load. Models available with 5 A, 10 A, 20 A, 50 A, and 200 A output current. |
HV Pulse Generator Instruments
 | See our High Voltage Pulse Generator Product Selection Guide here! DEI Scientific offers a variety of Pulse Generator Instruments designed for high voltage and precision applications such as Time of Flight, Q-Switches, Pockels Cells, acoustic transducers, microchannel plates, photomultiplier tubes and image intensifiers. These instruments are perfect for research & development, characterization and testing of dielectrics as well as many other high voltage pulsed applications. Looking for an OEM high voltage pulse generator module? Visit our High Voltage Pulse Generator Modules Product Catalog here. |
PVX-2506 50V 10A Pulse GeneratorThe PVX-2506 pulse generator is designed for pulsed I-V (current-voltage) characterization of semiconductor devices at up to 50 Volts and 10 Amps. It is also well suited for other applications requiring high current, precision voltage pulses. |
PVX-4110 10kV Pulse GeneratorThe PVX-4110 pulse generator produces fast, high voltage wave forms to 10,000V. Optimized for high impedance capacitive loads. | |
PVX-4130 6kV Pulse GeneratorThe PVX-4130 pulse generator produces fast, high voltage wave forms to 6,000V. Optimized for high impedance capacitive loads. |
PVX-4140 3.5kV Pulse GeneratorThe PVX-4140 pulse generator produces fast, high voltage wave forms to 3,500V. Optimized for high impedance capacitive loads. | |
PVX-4150 1.5kV Pulse GeneratorThe PVX-4150 pulse generator produces fast, high voltage wave forms to 1,500V. Optimized for high impedance capacitive loads. |
HV Pulse Generator Modules
 | DEI Scientific offers a variety of High Voltage Pulse Generator Modules designed for high voltage and precision applications such as Time of Flight, Q-Switches, Pockels Cells, acoustic transducers, microchannel plates, photomultiplier tubes and image intensifiers. These Modules are perfect for OEM designs as well as both permanent or semi-permanent installations. Looking for a benchtop high voltage pulse generator instrument? Visit our High Voltage Pulse Generator Instruments Product Catalog here. |
PVM-1001 950V Pulse Generator ModuleThe PVM-1001 is a state-of-the-art, high frequency, high power module designed to achieve zero to 950 V in less than 10 ns (Rise Time) into a 50 Ohm load. This adjustable pulsed voltage source is capable of providing pulse widths from 55 ns to 10,000 ns with a standard frequency range up to 1MHz. |
PVM-4210 ±950V Pulse Generator ModuleThe PVM-4210 is a compact, OEM-style pulse generator module providing two simultaneous differential voltage pulses of up to ±950V (1,900V differential). |
